Hallway Pine Shoe Rack
Hallway Pine Shoe Rack measures 30 W x 9.25 D x 34 H in, 4 boards cut from 2 pieces of stock with 4 butt joints.
What was checked: every part cut from real stock with the saw kerf, no two boards in the same space, every board touching another, shelf spans against the limit for the stock.
- Overall
- 30 W × 9¼ D × 34 H in
- Stock
- 2 x 1x10 pine, 8 ft
- Joints
- 4 butt joints, glue and screws
- Screws
- about 12
- Saw kerf
- 1/8 in
The first rows are free to read below. Every library pattern and its PDF are included with any plan.
| # | Item |
|---|---|
| 1 | 2 x 1x10 pine, 8 ft |
| Part | Qty | Cut size (T x W x L) |
|---|---|---|
| Side | 2 | 0.75 x 9.25 x 34 in |
| Shelf | 2 | 0.75 x 9.25 x 28.5 in |
Cutting plan (1/8 in kerf included):
Every library pattern and its PDF are included with any plan. The first rows, the supplies and the notes are free to read.
| Category | Item | Amount |
|---|---|---|
| lumber | 2 x 1x10 pine | 8 ft |
| hardware | About 12 1-1/4 in wood screws | 1 |
| hardware | Wood glue | 1 |
| finishes | Clear finish | 1 |
Inputs
Sizes are computed from these fixed inputs: kerf (in) 0.125, max shelf span (in) 32, target (in) 30, 9.25, 36, tol (in) 2. A different gauge or stock makes a different size; the counts do not change.
Brief
“Can you design a low two-shelf shoe rack for my hallway, 30 inches wide and about 9 inches deep, roughly 20 inches tall? I'm thinking whitewashed pine with the slats or boards left plain, nothing fancy.”
Checks
The counts, part sizes and placement were checked by computation on 30 September 2026 (verified on attempt 1); the piece has not yet been made by hand. If yours comes out differently, tell us and we will look at it.
